The FURIX FUVCT-900 Veterinary Fuvision CT Scan, also known as Vetease 3, is an advanced multi-modal imaging system engineered specifically for veterinary applications. It integrates four primary imaging modes—CT (Computed Tomography), DR (Digital Radiography), Dynamic DR (for real-time motion imaging), and Dental Panoramic—to provide a comprehensive solution for all X-ray-based diagnostic requirements in animal healthcare. This versatility allows veterinarians to perform a wide range of procedures without needing multiple devices, streamlining workflows in clinics and hospitals. The system features a ring-shaped structure that ensures stable and precise scanning, with a generous gantry dimension of at least 80cm to comfortably fit various animal sizes, from small pets to larger breeds.

Key functionalities include super 3D reconstruction in CT mode, enabling detailed volumetric rendering for accurate diagnosis of complex conditions such as fractures, tumors, or internal organ issues. The unique CT-AIR Technology optimizes air-based imaging enhancements, reducing artifacts and improving image clarity while minimizing radiation exposure to just 1/100th of traditional CT systems, prioritizing animal safety during repeated scans. Scanning is remarkably efficient, with the fastest mode completing in 12 seconds, allowing for quick assessments in emergency situations.

The system's working principle revolves around high-precision X-ray generation and detection:

• In CT mode, it rotates around the animal to capture 600 slices at 0.14mm thickness, reconstructing them into 3D models.
• DR and Dynamic DR modes utilize a large 43cm x 43cm flat-panel detector for static or fluoroscopic imaging, ideal for real-time procedures like joint evaluations or respiratory monitoring.
• Dental Panoramic mode curves the imaging path for full-mouth views in animals, aiding in oral health diagnostics.
• An upgraded DSA (Digital Subtraction Angiography) option enhances vascular imaging by subtracting background structures.

For installation and operation, the machine requires a dedicated space measuring at least 2.0m x 1.7m x 1.6m, standard electrical power supply (specifications not detailed in brochure, consult manufacturer), and trained veterinary staff. It supports clinical cases demonstrated in the brochure, including spinal reconstructions, thoracic scans, and cardiovascular visualizations, making it suitable for routine check-ups, surgical planning, and specialized veterinary practices.

Technical Specifications Table:

This detailed setup ensures the FURIX FUVCT-900 delivers high-quality, low-risk imaging, enhancing diagnostic accuracy and animal welfare in veterinary medicine.
